Description
Fujikura FSM-80S Fiber Optic Fusion Splicer
The Fujikura FSM-80S is core-to-core alignment single fiber splicer succeeding to FSM-60S. In addition to ruggedized concept, which 60S created, the 80S has a series of new features, such as “Automated wind-protector and tube-heater” for quicker splicing cycle as well as fewer operation steps, “innovative carrying-case design” for
quicker preparation, “powerful Li-ion battey” for longer operation, high resolution bigger LCD monitor, and “built-in operation manuals” in various languages. Market is from backbone network installation to opto-electronics components production for quality splice.
Features Fujikura FSM-80S
- Color LCD monitor & 256 magnification
- Compact & Light weight
- Reversible monitor with control panel on each side
- Max. wind velocity of 15m/s.
- 8 Sec. splice time, 40 Sec. tube-heat time
- Simultaneous X and Y views
- Large capacity internal battery
- SYSTEM TEST ensures the best working condition
- User programmable
- Auto check fiber end face
- Auto calibrate parameters
- Auto calibrate parameters
- Multiple language options
Specification FSM-80S
| PARAMETER | VALUE |
| Model | FSM-80C Fusion Splicer |
| Applicable Fibers | Single-mode (G.652 & G.657), Multimode (G.651), DS (G.653), NZDS (G.655) |
| Fiber Count | Single, 2, 4, 5, 6, 8, 10, 12 |
| Cladding Diameter | 125 μm |
| Coating Diameter | Ribbon: 0.25 mm to 0.4 mm, Single: 250 μm and 900 μm |
| Fiber Cleave Length | 10 mm |
| Typical Average Splice Loss | 0.05 dB with SM, 0.02 dB with MM, 0.08 dB with DS, 0.08 dB with NZDS;measured by cut-back method relevant to ITU-T standards |
| Splicing Time | Typical 15 seconds with standard single-mode fiber |
| Arc Calibration Method | Automatic, real-time by using results of previous splice when in AUTO mode; manual arc calibration function available |
| Splicing Modes | 100 preset and user programmable modes |
| Splice Loss Estimate | Based upon dual camera cladding alignment data |
| Storage of Splice Result | Last 2000 splice results stored in the internal memory |
| Fiber Display | X or Y, or both X and Y simultaneously; front or rear monitor display options with automatic image orientation |
| Magnification | 35X to 90X |
| Viewing Method | Dual cameras with 4.7 inch TFT color LCD monitor with anti-reflective coating |
| Operating Condition | 0 to 3,660 m above sea level, 0 to 95% RH, and -10 to 50°C respectively |
| Mechanical Proof Test | 1.96 to 2.25 N |
| Tube Heater | Built-in tube heater with 30 heating modes; auto-start function |
| Tube Heating Time | Typical 40 seconds with FP-5 sleeve, 17 seconds with FP3 (40), 5-15 seconds with Fujikura micro sleeves |
| Protection Sleeve Length | 60 mm, 40 mm, Micro |
| Splice/Heat Cycles with Battery | Typical 110 cycles with power save functions activated |
| Electrode Life | 1,500 Arc Discharges |
| Power Supply | Auto voltage selection from 100 to 240V AC or 10 to 15V DC with ADC-18, 14.8V DC with BTR-09 battery |
| Terminals | USB 2.0 (USB-B type) for PC communication and Mini-DIN (6-pin) for HJS-02/03 |
| Wind Protection | Maximum wind velocity of 15m/s (34 mph) |
| Dimensions | 146 W x 159 D x 150 H (mm) / 5.7 W x 6.3 D x 5.9 H (inches) |
| Weight | 2.3 kg (5.1 lbs) with AC adapter; 2.5 kg (5.5 lbs) with battery |
Additional information
| Lead Time | 3-5 Days |
|---|---|
| Packaging | Box |
