Description
Stonex S800 GPS RTK GNSS
The Stonex S800 GNSS receiver has a unique design, excellent signal tracking ability and interference resistant capacity. Because of it’s portability and speed of operation, the S800 is well suited for fieldwork in areas with complex terrain. It is ideal for any surveying field work and can communicate with any other type of receiver in a simple and efficient way because of its UHF internal radio that has several transmission protocols.
It supports multiple GNSS signals including GPS, GLONASS, BeiDou and Galileo and is equipped with 555 channels. To optimize space and increase performance, the receiver is equipped with GNSS, Bluetooth and Wi-Fi integrated modules and has an independent R&D LINUX+CORTEX intelligent platform.
The device has a Web UI control to download data using portable or PC, smartphone or tablet with Wi-Fi capability and to initialize, manage and monitor the settings of the receiver. 5 individual slots are available for the antenna, radio, board card, main board and battery as the result of the aluminum alloy capsule design.
Maximum durability is guaranteed by its strong external magnesium alloy framework which can endure a 2 meter pole drop on concrete floor with no damage. Its water/dust proof design is IP67 certified. It is delivered with an internal battery of 6800mAh that guarantees continuous working up to 10 hours.
Features Stonex S800 :
- Supports all GNSS signals including GPS, GLONASS, BeiDou and Galileo
- Multi constellation
- 6800mAh battery capacity
- Web UI control
- Internal UHF Radio Modem
- IP67 Certified Rugged Design
Specificaitons :
| Channels: | 555 |
| GPS: | L1C/A, L1C, L2P, L2C, L5 |
| GLONASS: | L1C/A, L2C, L2P, L3, L5 |
| BeiDou: | B1, B2, B3 |
| Galileo: | E1, E5 AltBOC, E5a, E5b, E6 |
| QZSS: | L1C/A, L1C, L2C, L5, L6 |
| SBAS: | L1, L5 |
| IRNSS: | L5 |
| Position Rate: | 5 Hz, optional up to 20 Hz |
| Signal Reacquisition: | < 1 sec |
| RTK Signal Initialization: | Typically < 10 s |
| Hot Start: | Typically < 15 s |
| Initialization Reliability: | > 99.9 % |
| Internal Memory: | 8 GB |
| Battery: | Rechargeable 7.2 V-6800 mAh Rechargeable 7.2 V-5200 mAh |
| Voltage: | 9 to 18 V DC external power input with over-voltage protection (5 pins Lemo) |
| Working Time: | 10 hours |
| Charge Time: | Typically 4 hours |
| Weight: | 1.2 Kg |
| Dimensions: | 146 mm x 146 mm x 76 mm |
| Operating Temperature: | -40 °C to 65 °C |
| Storage Temperature: | -40 °C to 80 °C |
| Waterproof/Dustproof: | IP67 |
| Shock Resistance: | Designed to endure to a 2m drop pole on concrete floor with no damage |
| Vibration: | Vibration resistant |
