Description
Leica BLK2GO Handheld Laser Scanner
The Leica BLK2GO handheld imaging laser scanner recreates spaces in 3D as you move. It captures images and dimensionally accurate point clouds in real-time and uses SLAM technology to record your trajectory through space.
FAST
Scan as you go with no interruptions. Digital reality capture of the space around you happens in real time as you move through it.
AGILE
Scan over and under objects, through rooms and doorways, around corners, and up and down stairwells. Using SLAM spatial awareness technology, BLK2GO knows where it is and where it has been in space.
SEAMLESS CAPTURE
Like a torch for visualising three-dimensional reality, the BLK2GO automatically builds 3D point clouds while in motion. From the moment you begin a scan session until the moment you turn off the BLK2GO, all imagery and 3D data are combined.
UNBOUND
No tripod. Onboard data collection. Continuous scanning on rechargeable battery power.
Leica BLK2GO Specs
DUAL AXIS LIDAR DOME
The smallest dual axis LiDAR available with best-in-class accuracy, enclosed in a fully protected and encapsulated dome that scans up to 420,000 points per second. Both axes constantly spin while scanning.
MULTICAMERA VISION SYSTEM
The BLK2GO’s vision system is a 12-megapixel detail camera for brilliant high-contrast imagery plus three panoramic cameras for visual navigation via SLAM, point cloud colourisation and capture of panoramic imagery.
THE GRANDSLAM
The GRANDSLAM (Simultaneous Localization and Mapping) is a combination of high-speed dual axis LiDAR, multi-camera vision system and an inertial measurement unit that makes the BLK2GO self-navigating.
LIGHTWEIGHT ALUMINUM CONSTRUCTION
Weighing in 775 grams (1.7 lbs.) with battery, the BLK2GO’s matte-finish aluminum construction allows for excellent dexterity and freedom of movement.
SMART HANDLE
The BLK2GO’s handle contains WLAN connectivity, a rechargeable battery capable of 45 minutes of continuous scanning, data storage for six hours of scans, a USB-C port for fast data transfer and edge computing.
ADVANCED LIGHTGUIDE
The light guide that encircles the BLK2GO is simple, intuitive and communicative to users of all skill levels. It provides user guidance while scanning and communicates the device status and data quality.
In The Box Leica BLK2GO
- Leica BLK2GO Handheld Laser Scanner
- Transportation Case
- 3x GEB821 Li-Ion Battery
- GKL821 Multi Charge with AC Adapter
- Table Stand
- USB C Cable
- Wrist Strap
- Quick Guide
- USB Documentation Card
Specification Leica BLK2GO :
|
DESIGN & PHYSICAL |
|
| Housing | Black anodized aluminium |
| Dimensions | Height: 279 mm / Diameter: 80 mm |
| Weight | 650 g (775 g including battery) |
| Transport cover | BLK2GO transportation case |
|
OPERATION |
|
| Stand-alone operation | One-button operation |
| Mobile device | BLK2GO Live app for iOS and Android including: live 2D and 3D while scanning, device status and data management.iOS 12.1 or higher recommended devices: iPhone series 8, X, 11, 12 Android 9 or higher. Recommended devices: Samsung Galaxy series S10, S20, S21 |
| Communication | Wireless (app connection) |
| Internal memory | 24 hours of scanning (compressed data) / 6 hours (uncompressed data) |
| Battery | Exchangeable, rechargeable Li-Ion battery (Leica GEB821) 45-50 minutes |
|
LiDAR & IMAGING |
|
| Laser class | 1 (in accordance with IEC 60825-1) |
| Wavelength | 830 nm |
| Field of view | 360° (horizontal) / 270° (vertical) |
| Range | Min. 0.5 – up to 25 m |
| Point measurement rate | 420,000 pts/sec |
| High resolution camera | 12 Mpixel, 90° x 120°, rolling shutter |
| Panoramic vision system | 3-camera system, 4.8 Mpixel 300° x 135°, global shutter |
|
SYSTEM PERFORMANCE |
|
| Range noise * ** | +/-3 mm |
| Accuracy indoor *** | +/-10 mm |
|
ENVIRONMENTAL |
|
| Robustness | Designed for indoor and outdoor use |
| Operating temperature | 0 to +40 °C |
| Dust & humidity protection | IP54 (IEC 60529) |
|
DATA PROCESSING |
|
| Data transfer | Wireless and USB 3.0 |
| Desktop software | Leica Cyclone REGISTER 360 and Cyclone REGISTER 360 (BLK Edition) |
Additional information
| Lead Time | 3-5 Days |
|---|---|
| Packaging | Box |
